How do I clip a reference in Autocad?
To Clip an Xref Click Modify menu > Clip > Xref. Select an xref. At the prompt, specify New Boundary by pressing Enter. Select a polyline or specify a rectangular or polygonal clipping boundary. (Optional) Use the Invert Clip option to change the area to be hidden from outside to inside the clipping boundary. Click to see full answer. Then, how do I mask a reference in Autocad?Click Mask Block Reference tab Modify panel Attach Objects. Select the object that you want to mask. Select a display representation from the list of current display representations, and click OK.Similarly, how do I hide clipping boundaries in Autocad? To Show or Hide Image Boundaries Click Modify menu Object Image Frame. To hide image boundaries, enter 0; to show and plot image boundaries, enter 1; to show image boundaries but not plot them, enter 2. how do you clip in Autocad? To clip an xref or block, use the XCLIP command. Choose Insert tab>Reference panel> Clip. Select the xref or block and press Enter to end selection. At the [ON/OFF/Clipdepth/Delete/generate Polyline/New boundary]
